Iiyama TF2215MC-B2

Artikelcode TF2215MC-B2
EAN-code 4948570116768
Toepassing Interactive / Touch

Heeft u interesse in de aanschaf van dit product?

Uitgelichte functionaliteiten
Specificaties
The ProLite TF2215MC-B2 (21.5 inch) uses PCAP touch technology and is built into an eye-catching bezel with edge-to-edge glass. Thanks to a glass overlay covering the screen and a rugged bezel, it guarantees high durability and scratch-resistance, making it perfect for kiosk and high use public facing applications. Equipped with a foam seal finish it supports seamless integration into kiosks and provides IP65 rating resulting in dust and water resistance from the front. Landscape, portrait and face-up orientation ensures flexible mounting possibilities in almost any installation. For ease of integration, the TF2215MC-B2 comes equipped with external mounting brackets making it an ideal solution for kiosk integrators, industrial environments, control rooms and interactive multimedia. TOUCH THROUGH-GLASS This through glass touch screen works right through glass and can turn glass surfaces into an interactive touch screen display. Use it on storefront windows, real estate office, in-store for POS or restaurants. TOUCH TECHNOLOGY - CAPACITIVE This technology uses a sensor-grid of micro-fine wires integrated into the glass that covers the screen. Touch is detected because electrical characteristics of the sensor grid change when human finger is placed on the glass. Thanks to the glass overlay this technology is highly durable, and the touch function remains unaffected even if the glass is scratched. It offers perfect picture performance and will work with human finger (also latex gloved) and stylus-pen. OPEN FRAME BRACKETS This open frame monitor comes equipped with external mounting brackets. It guarantees easy installation and makes it an ideal solution for kiosk integrators and Instore Retail. FOAM SEAL A foam seal finish (8mm) around the monitor ensures seamless integration and optimal dust protection. ANTI-FINGERPRINT COATING This special Nano coating ensures a smoother touch and less resistance in the swipe. It makes the screen less static and susceptible to dirt, dust, fingerprints and it improves the clarity of the content displayed on the screen.

Technische details

Soort paneel
IPS
Hoeveelheid simultane aanraakpunten
10
HDCP
Ja
Ophangsysteem voor aan de muur
Ja

Beeldscherm

Beeldschermdiagonaal
22 "
Resolutie
1920 x 1080 Pixels
Helderheid
315 cd/m²
HD type
Full HD
Responstijd
14.0 ms
Typische contrastverhouding
1000:1
Kijkhoek, horizontaal
178.00 °
Kijkhoek, verticaal
178.00 °
Beeldscherm, aantal kleuren
16.78 million colours
Pixel pitch
0.24795 x 0.24795 mm
Schermdiameter in centimeters
54.600 cm
Touchscreen technologie
Projected capacitive system
Oorspronkelijke beeldverhouding
16:9
Beeldscherm vorm
Flat screen
Display technologie
LED
Touch screen type
Multi-user
Touchscreen
Ja
Touch technologie
Multi-touch
Beeldverhouding
16:9

Audio

Ingebouwde microfoon
Nee

Poorten & interfaces

HDMI
Ja
Aantal HDMI-poorten
1
VGA (D-Sub)poort(en)
1
Aantal DisplayPorts
1
Hoofdtelefoonuitgangen
1
Displayport poorten
1
VGA poorten
1
Totaal aantal outputs
2
HDMI poorten
1

Gewicht en omvang

Breedte ( zonder voet )
520.0 cm
Diepte ( zonder voet )
42.5 cm
Hoogte (zonder voet )
315.0 cm
Breedte
520.00 mm
Diepte
42.50 mm
Hoogte
315.00 mm
Gewicht
4400.000 g

Energie

Stroomverbruik (typisch)
19.00 W
Stroomverbruik (in standby)
1.20 W
Stroomverbruik (indien uit)
1.200 W
Energie-efficiëntieklasse
A

Eisen aan de omgeving

Bedrijfstemperatuur (T-T)
0 - 40 °C
Relatieve vochtigheid in bedrijf (V-V)
20 - 80 procent
Temperatuur bij opslag
-20 - 60 °C
Luchtvochtigheid bij opslag
10 - 90 procent

Certificaten

Certificering
CB, CE, TÜV-Bauart, CU, cULus, REACH

Beheerfuncties

Aantal On Screen Display-talen
6

Ergonomie

VESA-montage
Ja
Paneelmontage-interface
100 x 100 mm
On Screen Display (OSD)-talen
DEU,ENG,ESP,FRE,ITA,JPN
Plug and play
Y

Inhoud van de verpakking

Inclusief AC-adapter
Y
Meegeleverde kabels
AC,DisplayPort,HDMI,USB
Snelstartgids
Ja

Overige specificaties

Effectieve beelddiameter
476.064 x 267.786 mm
Ondersteuning voor plaatsing
Horizontal/Vertical

Design

Type beeldscherm
LED
Kleur van het product
Black
Internationale veiligheidscode (IP)
IP65

Prestatie

Apparte H/V sync
Ja
Frequentiebereik horizontaal
31.4 - 82 kHz
OmniTapps Multitouch compatibiliteit
Nee
Soort voeding
DC
Frequentiebereik verticaal
56 - 75 Hz

Duurzaamheid

Europees Productregister voor Energielabeling (EPREL) code
378611

Video

Volledige HD
Ja

Multimedia

Ingebouwde camera
Nee

Energie-efficiëntieschaal
A to G
Energie-efficiëntieklasse (SDR)
F
Energieverbruik (SDR) per 1000 uur
19 kWu
Gewicht (zonder voet)
4400.00 kg
AMD FreeSync
N
NVIDIA G-SYNC
Nee
USB Touch port
Y
Code geharmoniseerd systeem (HS)
85285210
Energie-efficiëntieklasse (oud)
A
