B-Tech BT8309/B V2
Item code
BT8309/B V2
EAN-code
5019318440588
Downloads
Click here for the downloads
Are you interested in purchasing this product?
Related products
Highlighted functionality
Specifications
The BT8309 is designed to install small to medium screens into recessed walls. The pop-out mechanism allows for a flush to the wall installation while still allowing access to the rear of the screen for easy installation and service access. Tool-less micro-adjustment is included on each corner to allow screens to perfectly align to the recess and additional screens in a videowall installation. BT8309 also allows screens to be mounted in landscape or portrait orientation and is compatible with B-Tech's professional pole and collar system for pole-mounted installs.
Weight & dimensions
Width
220.00 mm
Height
287.00 mm
Ergonomics
Adjustable depth
Yes
Angle of rotation
360 °
Panel mounting interface
75 x 75,200 x 200 mm
Swivel angle
180 °
Distance to the wall (max)
73.0 mm
Distance to the wall (min)
69.00 mm
Cable management
Yes
Tilt angle range
-15 - 15 °
Packaging content
Mounting kit
Yes
Design
Product colour
Black
Mounting
Suitable for computer monitor
Yes
Maximum screen size
1060.0 mm
Mounting type
Wall
Number of displays supported
1
Maximum weight capacity
25.000 kg
Minimum VESA mount
75 x 75 mm
Maximum VESA mount
200 x 200 mm
Logistics data
Products per master (outer) case
12 pc(s)
Master (outer) case volume
0.055 cm³
Master (outer) case gross weight
14600 kg
